Code | ||||
|---|---|---|---|---|---|
| T0 300 0000 | |||||
SWL Safe Working Load:
*Bending moment of the pendant bracket at the ceiling plate
(M1 according to the paragraph 10.8.2.1 of the standard EN 61537:2007, verified with the test configuration shown in figure 7a carried out on the item equipped with a slotted “C” section item no. T0 041 2000 0.8 m long)
** Tensile strength of the pendant bracket
(F according to the paragraph 10.8.2.2 of the standard EN 61537:2007, verified with the test configuration shown in figure 7b carried out on the item equipped with a slotted “C” section item no. T0 041 2000 0.8 m long)
| 01 | Galvanization (Sendzimir method) - UNI EN 10346 | |
| 40 | Stainless steel AISI 304 - UNI EN 10088 |
| Certified System |
EN 61537-1 ed.2007
EN 50085-1:2005 ed EN 50085-2-1:2006
IMQ
 |
n.2 M8x12 | T0 623 0812 |
 |
n.1 M8 | T0 624 0800 |
Not included
